Archer AX4200
NewAX4200 Tri-Band Wi-Fi 6 Router
- Rapid 4.2 Gbps Tri-Band Wi-Fi – 2402Mbps (5 GHz) + 1201 Mbps (5 GHz) + 574 Mbps (2.4 GHz).
- Ultra Connectivity – 5× Ethernet ports and two USB ports ensure max flexibility and boosted throughput.
- Maximized Coverage – Seven high-gain antennas equipped with Beamforming ensure vast coverage.
- More Devices with Less Lag – OFDMA and MU-MIMO technology deliver data to multiple devices, simultaneously.
- Powerful CPU – 1.5 GHz quad-core processor ensures fast transmission speeds and smooth operation of numerous devices and applications.
- Refined Security – WPA3 reinforces Wi-Fi encryption for improved security.
Faster. Broader. Unstoppable.
AX4200 Tri-Band 6-Stream WiFi 6 Router
Upgrade Your WiFi to 6
Ideal for Your Latest Phones and Laptops
The new generation of phones—such as iPhone 12 and Galaxy S21—and laptops already support WiFi 6, with many more on the way. Your router should, too. WiFi 6 holds great promise to future-proof your home network for the next several years. Now is the best time to embrace this new technology.
-
4× Larger
Capacity -
3× Faster
Speed -
Save Devices’
Power -
Backwards
Compatible
Powerful and Exquisite
Combining Tri-band WiFi with high-tech WiFi 6, Archer AX4200 provides seven simultaneous data streams to open up more bandwidth and help your devices operate at full speed. Six high gain antennas not only deliver boosted WiFi signals to every corner of your home, but also bring a sense of aesthetics.
-
Tri-Band
-
6 Streams
Go Faster—
Wired or Wireless
In addition to stunning wireless speeds of more than 4.2 Gbps, Archer AX4200 also provides premium wired connections. A 2.5 Gbps port and 1 Gbps port make full use of gigabit speeds from your local ISP. Break through the 1G bottleneck and drive your devices to peak performance. WAN/LAN support gives you remarkable flexibility to tailor both ports to fit your network’s needs.
Your Security is Our Priority
Let the Experts Secure Your Home
Customize your home network with enhanced security using TP-Link HomeShield's kit of built-in features. Whether you're identifying network security holes, limiting the time your children spend online, or blocking websites, HomeShield gives you the tools you need to fully manage your network.
 Home Network ScannerThe security threats to your home network are continually evolving as your WiFi usage grows. HomeShield provides a home network scanner for your private WiFi to detect potential threats and alert you of security issues. |
 Parental ControlsWhether you want to block inappropriate websites, set daily limits for the total time spent online, see which sites your kids are using, or pause the internet, you can do it with parental controls—all from the convenience of an app. |
 Quality of ServiceChoose devices or activities you want to prioritize on your network with Quality of Service (QoS). In just a few taps, make sure your laptop or movie stream is first in line for WiFi or Ethernet. |
 Comprehensive ReportsHomeShield constantly monitors your home network security, keeps an eye on your WiFi usage, and generates weekly and monthly reports. This helps you gain insight and better control of your home network. |
WPA3—Stronger Security for Your Network
Building on the widespread adoption of WPA2, the latest WPA3 brings new capabilities to improve cybersecurity.
-
Protection against Brute-Force Attacks -
Improved Systems for Adding Devices -
Stronger Wi-Fi Encryptions
TP-Link OneMesh™ :
Flexibly Create Whole Home WiFi with Archer AX4200
OneMesh™ is a simple way to form a Mesh network with a single WiFi name for seamless wholehome coverage. Just connect a OneMesh™ range extender to a OneMesh™ router. No more searching around for a stable connection.
Wi-Fi Dead-Zone KillerEliminate weak signal areas with Wi-Fi coverage for the whole house |
Smart RoamingUninterrupted streaming when moving around your home |
One Wi-Fi NameNo more switching Wi-Fi network names |
Unified ManagementManage the whole-home Wi-Fi by managing the central node via Tether app/Web UI |
| WIRELESS | |
|---|---|
| Standards | Wi-Fi 6IEEE 802.11ax/ac/n/a 5 GHzIEEE 802.11ax/n/b/g 2.4 GHz |
| WiFi Speeds | AX42005 GHz: 2402 Mbps (802.11ax, HE160)5 GHz: 1201 Mbps (802.11ax)2.4 GHz: 574 Mbps (802.11ax) |
| WiFi Range | 3 Bedroom Houses 6× Fixed High-Performance AntennasMultiple antennas form a signal-boosting array to cover more directions and large areasBeamformingConcentrates wireless signal strength towards clients to expand WiFi rangeHigh-Power FEMImproves transmission power to strengthen signal coverage |
| WiFi Capacity | Very High Tri-BandAllocate devices to different bands for optimal performanceOFDMASimultaneously communicates with multiple Wi-Fi 6 clientsAirtime FairnessImproves network efficiency by limiting excessive occupation6 StreamsConnect your devices to more bandwidth |
| Working Modes | Router ModeAccess Point Mode |
| SECURITY | |
|---|---|
| Network Security | SPI FirewallAccess ControlIP & MAC BindingApplication Layer Gateway |
| Guest Network | 1× 5 GHz-1 Guest Network1× 5 GHz-2 Guest Network1× 2.4 GHz Guest Network |
| VPN Server | OpenVPNPPTP |
| WiFi Encryption | WPAWPA2WPA3WPA/WPA2-Enterprise (802.1x) |
| HARDWARE | |
|---|---|
| Processor | 1.5 GHz Quad-Core CPU |
| Ethernet Ports | 1× 2.5 Gbps WAN/LAN Port1× 1 Gbps WAN/LAN Port3× 1 Gbps LAN Ports |
| USB Support | 1× USB 3.0 Port1× USB 2.0 PortSupported Partition Formats:NTFS, exFAT, HFS+, FAT32Supported Functions:Apple Time MachineFTP ServerMedia ServerSamba Server |
| Buttons | Wi-Fi On/Off ButtonPower On/Off ButtonLED On/Off ButtonWPS ButtonReset Button |
| Power | 12 V ⎓ 3.3 A |
| SOFTWARE | |
|---|---|
| Protocols | IPv4IPv6 |
| OneMesh™ | OneMesh™ SupportedWithout replacing your existing devices or buying a whole new WiFi ecosystem, OneMesh™ helps you create a more flexible network that covers your entire home with TP-Link OneMesh™ products.Learn More>All OneMesh Products> |
| Parental Controls | URL FilteringTime Controls |
| WAN Types | Dynamic IPStatic IPPPPoEPPTPL2TP |
| Quality of Service | QoS by Device |
| Cloud Service | Auto Firmware UpgradeTP-Link IDDDNS |
| NAT Forwarding | Port ForwardingPort TriggeringDMZUPnPVirtual Server |
| IPTV | IGMP ProxyIGMP SnoopingBridgeTag VLAN |
| DHCP | Address ReservationDHCP Client ListServer |
| DDNS | TP-LinkNO-IPDynDNS |
| Management | Tether AppWebpage |
| OTHER | |
|---|---|
| System Requirements | Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browserCable or DSL Modem (if needed)Subscription with an internet service provider (for internet access) |
| Certifications | FCC, CE, RoHS |
| Environment | Operating Temperature: 0℃~40℃ (32℉ ~104℉)Storage Temperature: -40℃~70℃ (-40℉ ~158℉)Operating Humidity: 10%~90% non-condensingStorage Humidity: 5%~90% non-condensing |
| TEST DATA | |
|---|---|
| WiFi Transmission Power | CE:<20dBm{2.4GHz}<23dBm{5.15GHz~5.35GHz}<30dBm{5.47GHz~5.725GHz}FCC:<24dBm{5.47GHz~5.725GHz }<30dBm{2.4GHz &5.15GHz~5.25GHz&5.725GHz~5.825GHz } |
| PHYSICAL | |
|---|---|
| Dimensions (W×D×H) | 11.9 × 8.1 × 6.8 in(302 × 207 × 174 mm) |
| Package Contents | Wi-Fi Router Archer AX4200Power AdapterRJ45 Ethernet CableQuick Installation Guide |
†Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of network conditions, client limitations, and environmental factors, including building materials, obstacles, volume and density of traffic, and client location.
‡Use of Wi-Fi 6 (802.11ax), and features including OFDMA, MU-MIMO, 1024-QAM or HE160 require clients to also support the corresponding features.
§2.5 Gbps internet speeds require compatible service plans and equipment.
△Saving clients' battery power requires clients to also support the 802.11ax Wi-Fi standard. Actual power reduction may vary as a result of network conditions, client limitations, and environmental factors.
**Use of WPA3 requires clients to also support the corresponding feature.
***This router may not support all the mandatory features as ratified in Draft 3.0 of IEEE 802.11ax specification.
****Further software upgrades for feature availability may be required.
Actual network speed may be limited by the rate of the product's Ethernet WAN or LAN port, the rate supported by the network cable, Internet service provider factors and other environmental conditions.
